CS Series Cone Crusher

Overview of CS Series Cone Crusher:

CS Series Cone Crusher machine is used widely at present, Compared to the traditional spring cone crusher, the structure of the CS Series Cone Crusher with high-efficiency is more perfect, and its technical parameters are more advanced. CS Series Cone Crusher machine has excellent performance in the manufacture, installation, operation and maintenance. The cone crusher is the best choice for mining crusher with fine crushing, high productions and low maintenance.

The application of CS Series Cone Crusher:

CS Series Cone Crusher machine has been designed to crush high or medium hardness raw materials, such as ore, copper ore, limestone, quartz, granite, nonferrous metal ore and rocks etc. CS Series Cone Crusher machine is used in metallurgical industry, mining and construction, road building, chemical, silicate Industries, cement making industry etc.

CS Series Cone Crusher can be used in aggregate crushing plant, coal crushing plant, aggregate crushing plant, copper ore crushing plant, gold mining, marble crushing, cement production line, limestone crushing plant, etc.

+ Go

Features and benefits of CS Series Cone Crusher:

1. Many types of crushing chamber.ZENT CS Series Cone Crusher with high-efficiency owns special design, customers can choose the crushing chamber according to the situation.
2. Dry oil seal system.ZENT CS Series Cone Crusher has special seal structure, which extends the lubricants’ replacement cycle and the life of spare parts.
3. Special material is adopted on the key components of ZENT CS Series Cone Crusher to support large crush power.
4. High productivity .Compared with other type of crusher machine, ZENT CS Series Cone Crusher has longer crush arm, larger stroke, higher crush power.
5. The crushing cone has long distance from bowl liner in every stroke, so the CS Series Cone Crusher allows more materiel to get into the cavity and produces larger capacity.
6. Low cost of daily run and maintenance.

Working principle of CS Series Cone Crusher:

Through a horizontal axle and a pair of bevel gear, the motor drives the eccentric sleeve to revolve. The revolution of the eccentric sleeve makes the mantle move towards to the bowl liner from time to time. In this way, the ores and rocks will be pressed and finally crushed.

CS Series Cone Crusher Technical Data:

Type	Dia. of cone mm (inch)	Cavity	Feed Opening (mm)		Discharge Setting (mm)	Capacity (t/h)	Counter Shaft (r/min)	Power (kw)	Weight (t)	Overall Dimension (mm)
			Closed Side"B"	Opening Side"B"
CSB75	900(3')	Fine	83	102	9-22	45-91	580	75	15	2821×1880×2164
		Coarse	109	175	13-38	59-163
CSB110	1200(4')	Fine	127	131	9-31	63-188	485	110	20	2821×1974×2651
		Medium	155	156	13-38	100-200
		Coarse	178	191	19-51	141-308
CSB160	1295(4 1/4')	Fine	109	137	9-31	109-181	485	160	27	2800×2342×2668
		Medium	188	210	13-38	132-253
		Coarse	215	241	19-51	172-349
CSB240	1650(5 1/2')	Fine	188	209	16-38	181-327	485	240	55	3911×2870×3771
		Medium	213	241	22-51	258-417
		Coarse	241	268	25-64	299-635
CSB315	2134(7')	Fine	253	278	19-38	381-726	435	315	110	4613×3251×4732
		Medium	303	334	25-51	608-998
		Coarse	334	369	31-64	789-1270

Note: This specification is just reference, any changes are subject to the CS Series Cone Crusher products.
